OpenLM System Requirements

Check out the system requirements for installing OpenLM products and components.

Infrastructure minimum hardware requirements

  • Dual-core CPU
  • 8 GB memory
  • SDK v3.1.416 or higher (official download link)
  • Static MAC address (Cloud-based servers must use ENI)

We also recommend consulting the optimal configuration guide for more in-depth information.

V21 and higher OpenLM TCP ports configuration

Component Machine Inbound Outbound Comment
OpenLM Server 5015
5000 In case Identity Service is used.
7026 In case DSS is used.
5005 In case ServiceNow (External Platform Service) is used.

1433 (MSSQL)

3306 (MySQL/Maria)

According to the DB used and the port

the DB is using.

IdentityService 5000
5015 Server
7026 If DSS should be configured.
8888 If ReportScheduler should be configured.
443 In case External Providers are required.
DSS 7026
  5015 Server
  5000 In case Identity Service is used
EUS 53555   Websockets with Agents
  5000 Identity (in case it’s used)
  5015 Server
ServiceNow
(External Platform\Pentaho)
5005
5015 Server
443 HTTPS ServiceNow instance

1433 (MSSQL)

3306 (MySQL/Maria)

For OpenLM DB
Applications Manager  27080
5015 API for vendor filtering and security
5000 Identity (in case it’s used)
Reports Scheduler 8888
5015 API for email settings and user emails
5000 Identity
Broker 5090   Optional. Configuration time only
5015 Server
5000 Identity (in case it’s used)
Agent   53555 End-User Services
  27080 App Manager (in case it’s used)
  5015 Server
  5000 Identity (in case it’s used)
DSA

(8081: For hosting only)

  7026 DSS
  5000 Identity (in case it’s used)
  Directories ports According to the directory scanned
External DB DB port



HTTP Server

OpenLM is provided with integrated Kestrel support

OpenLM Server Supported Operating Systems

OpenLM Server uses ASP.Net Core 3.1 and can be generally installed on any .Net Core 3.1 supported platforms.

Windows

Supported versions: Windows 10 and above, Windows Server 2016 and above. Windows Server 2022 has not been tested yet.

To install – download the MSI package from our download area

Linux

We tested CentOS 7 and 8, Ubuntu 21.04

Following packages need to be installed as a prerequisite

  • Powershell core 7.1 (usually PowerShell-7.1 but may differ, PowerShell-7.0 is enough)
  • .Net core 3.1 (dotnet-sdk-3.1)
  • Systemctl command (systemd)
  • redhat-lsb package (installed by default in Ubuntu)
  • libgdiplus

To install – download whether tar.gz package or rpm (recommended) from our download area



Supported Databases

The following database types are supported:

MS SQL Server:

Versions 2012, 2014, 2016, 2017, 2019 are tested and supported.

Check here for a list of best practices.

Additionally:

  • Set the collation to case-sensitive (CS)
  • It is recommended to connect using an SQL Server Authenticated user
  • Make sure the user is permitted to read, write and change the database (db_owner)

MySQL Server:

For new installations, we recommend using MySQL 8.

  1. Use this creation script:
CREATE SCHEMA `openlm_database_name` DEFAULT CHARACTER SET utf8mb4; COLLATE utf8mb4_bin ;

2. On the blank database, run the script

SET SQL_SAFE_UPDATES = 0

Check here for a list of best practices.

MariaDB:

MariaDB Server 10.6  (as a current stable version which we used for testing)

All new versions should be tested separately.



OpenLM EasyAdmin User Interface

OpenLM EasyAdmin is the OpenLM management interface. It is applicable to any standard browser. We tested it on the following browser types:

Mozilla Firefox

It is recommended to use the latest version.

Microsoft Edge

It is recommended to use the latest version (or at least Chromium-based Edge)

Google Chrome

It is recommended to use the latest version.

Infrastructure minimal hardware requirements

  • Dual-core CPU
  • 4 GB memory (Recommended – 8 GB)
  • SDK v3.1.416 or higher (official download link)
  • .NET Framework 4.7.2 Runtime to run the Server installer (official download links)
  • Static MAC address (Cloud-based servers must use ENI)

We also recommend consulting the optimal configuration guide for more in-depth information.

V5.6 OpenLM TCP ports configuration



Component Machine Inbound Outbound Comment
OpenLM Server 5015
7026 In case DSS is used.
5005 In case ServiceNow (External Platform Service) is used.

1433 (MSSQL)

3306 (MySQL/Maria)

According to the DB used and the port

the DB is using.

DSS 7026
  5015 Server
ServiceNow
(External Platform\Pentaho)
5005
5015 Server
443 HTTPS ServiceNow instance

1433 (MSSQL)

3306 (MySQL/Maria)

For OpenLM DB
Applications Manager  27080
5015 API for vendor filtering and security
Reports Scheduler 8888
5015 API for email settings and user emails
Broker 5090   Optional. Configuration time only
5015 Server
Agent   27080 App Manager (in case it’s used)
  5015 Server
DSA

(8081: For hosting only)
  7026 DSS
  Directories ports According to the directory scanned
External DB DB port



HTTP Server

OpenLM is provided with an integrated HTTP Server – LightTPD
OpenLM can also be configured to work with most standard HTTP servers. We tested the system with:
Apache HTTP Server version 2* – Fully supported
Microsoft IIS 6, 7, 7.5, 10 – Fully Supported.
Other HTTP servers should also work.



OpenLM Server Supported Operating Systems

OpenLM can monitor both Windows’ and Unix / Linux resident license server systems.
The OpenLM Server can be installed on a Windows’ machine only.

OS VERSIONOPENLM SERVER
Windows 7 SP1 32 bitTested, Fully Supported
Windows 7 SP1 64 bitTested, Fully Supported
Windows 8.1Tested, Fully Supported
Windows 8 32 bitNot Supported
Windows 8 64 bitNot Supported
Windows 10Tested, Fully Supported
Windows Server 2008 R2 32 bitNot Supported, deprecated by Microsoft.
Windows Server 2008 R2 SP1 64 bitNot Supported, deprecated by Microsoft.
Windows Server 2008 SP2 32 bitNot Supported, deprecated by Microsoft.
Windows Server 2008 SP2 64 bitNot Supported, deprecated by Microsoft.
Windows Server 2012 64 bitTested, Fully Supported
Windows Server 2012 R2 64 bitTested, Fully Supported
Windows Server 2016 64 bitTested, Fully Supported
Windows Server 2016 R2 64 bitTested, Fully Supported
Windows Server 2019Tested, Fully Supported

Supported Databases

OpenLM Server is delivered with an embedded Firebird DB, as well as with the possibility (and recommendation) to migrate to an external database. Version 5.6 is the last to support Firebird. We recommend upgrading to the latest version. The following database types are supported:

MS SQL Server:

Versions 2012, 2014, 2016, 2017, 2019 are tested and supported.
Version 2005 support has been discontinued in OpenLM Server version 3.1 due to Microsoft’s deprecation.

Additionally:

  • Set the collation to case-sensitive (CS)
  • It is recommended to connect using an SQL Server Authenticated user
  • Make sure the user is permitted to read, write and change the database (db_owner)

Firebird Server:

Version 2.5.5 is tested and supported.

MySQL Server:

Version 5.7 is tested and supported. OpenLM Server v4.4+ supports MySQL 8.

1. Use this creation script:

CREATE SCHEMA `openlm_database_name` DEFAULT CHARACTER SET utf8mb4;

2. On the blank database, run the script

SET SQL_SAFE_UPDATES = 0

Oracle DB
Not supported.



OpenLM EasyAdmin

OpenLM EasyAdmin is the OpenLM management interface. It is applicable to any standard browser. We tested it on the following browser types:

Mozilla Firefox
It is recommended to use the latest version.

Microsoft Edge
It is recommended to use the latest version.

Google Chrome
It is recommended to use the latest version.



Broker System Requirements
OpenLM Broker is designed to run on any platform supported by the license server.
OpenLM Broker requires Java to run.  It is recommended to use the latest release of Java 8 or 11.  OpenJDK is supported.
.NET Framework 4.5.2 or higher is required to run the installer on Windows machines.
Memory: 4 GB of RAM (recommended 8GB)



OpenLM Broker supported platforms

OS VERSIONOPENLM BROKERCOMMENTS
Microsoft Windows 2012 server
Tested, Fully SupportedProvided with installer and configuration wizard
Microsoft Windows 2012 R2 serverTested, Fully SupportedProvided with installer and configuration wizard
Microsoft Windows 2016 serverTested, Fully SupportedProvided with installer and configuration wizard
Microsoft Windows 2016 R2 serverTested, Fully SupportedProvided with installer and configuration wizard
Microsoft Windows Server 2019Tested, Fully SupportedProvided with installer and configuration wizard
Windows 7 32 bitTested, Fully Supported (only Broker v4.4)Provided with installer and configuration wizard
Windows 7 64 bitTested, Fully Supported (only Broker v4.4)Provided with installer and configuration wizard
Windows 8 32 bit Not Supported Not Supported
Windows 8 64 bit Not Supported Not Supported
Windows 8.1Tested, Fully SupportedProvided with installer and configuration wizard
Windows 10Tested, Fully SupportedProvided with installer and configuration wizard
Ubuntu 14.04, 16.x, 18.xTested, Fully SupportedProvided archive tar.gz file
CentOS 6, 7Tested, Fully SupportedProvided archive tar.gz file
Other Unix/Linux OSShould work.Provided archive tar.gz file

The OpenLM Applications Manager should be installed on the same machine as the License Server (e.g. FLEXlm), adjacent the OpenLM Broker. It is implemented as a Java application, and as such it can run on any operating system that supports Java; e.g. Windows or Unix / Linux.

.NET Framework 4.5.2 or higher is required to run the installer on Windows machines.

We recommend consulting the optimal configuration guide for Applications Manager for a more in-depth answer as to system requirements.





OpenLM Reporting Hub System Requirements

The OpenLM Reporting Hub requires a Windows operating system, with the following minimum hardware requirements:

For small databases (under 100Gb):

  • RAM – 8GB
  • CPU – 2.1 Ghz+ Dual-Core
  • Storage – At least twice the size of your current OpenLM database, with room for growth.

For large databases (over 100Gb):

  • RAM – 16GB
  • CPU – 2.1 Ghz or higher Quad-Core
  • Storage – At least twice the size of your current OpenLM database, with room for growth.



Supported source database types:

  • MariaDB
  • SQL Server
  • MySQL

Supported destination database types:

  • PostgreSQL (Reporting Hub embedded database)
  • SQL Server
  • MySQL



Component Requirements

Data Integration

Java JDK 11

Postgres Server

Power BI Desktop



Infrastructure requirements
Minimum hardware requirements:
– a dual-core CPU
– 2 GB of RAM

Windows:
.NET Framework 4.7.2 Runtime to run the installer
Tested on Windows 10, Ubuntu 18, Ubuntu 20, and CentOS 8.

End-User Services is a self-contained .NET Core app – no runtimes are required to run the actual software since all files and libraries are bundled with the installers.
End-User Services need to be able to connect to these TCP ports: 5015 (default for OpenLM Server), 5000 (OpenLM Identity, if used) and listen to TCP 53555 (can be changed in appsettings.json).
Outbound connections are required for Browser notifications.





Infrastructure requirements
Minimum hardware requirements:
– a dual-core CPU
– 2 GB of RAM

Windows: .NET Framework 4.6 Runtime is required to run the installer.
Linux Agent requires pre-installed libXScrnSaver library when installing on CentOS, when using the tar.gz.
Tested on Windows 10, Ubuntu 18, Ubuntu 20, CentOS 8.

The Agent is a self-contained .NET Core app – no runtimes are required to run the actual software since all files and libraries are bundled with the installers.
The Agent needs to be able to connect to these TCP ports: 5015 (default for OpenLM Server), 27080 (Applications Manager), 53555 (OpenLM End-User Services), 5020 (OpenLM Identity, if used).





Infrastructure requirements
• .NET Framework 4.6.2 or higher;
• .NET Framework 3.5 for ArcGIS, versions older than 10.4.

OS VERSIONOPENLM AGENT
Windows 7 32 bitTested, Fully Supported
Windows 7 64 bitTested, Fully Supported
Windows 8.1Tested, Fully Supported
Windows 8 32 bitNot Supported
Windows 8 64 bitNot Supported
Windows 10Tested, Fully Supported
Windows Server 2008 R2 32 bitTested, Fully Supported
Windows Server 2008 R2 SP1 64 bitTested, Fully Supported
Windows Server 2008 SP2 32 bitNot Supported.
Windows Server 2008 SP2 64 bitNot Supported.
Windows Server 2012 64 bitTested, Fully Supported
Windows Server 2012 R2 64 bitTested, Fully Supported
Windows Server 2016 64 bitTested, Fully Supported
Windows Server 2016 R2 64 bitTested, Fully Supported





OpenLM Agent support for terminal servers
OpenLM Agent is built to work on any terminal server software (e.g. Microsoft Terminal Server, Citrix). If you have installed the OpenLM Agent on a terminal server software other than the ones elaborated below – please update us.

TERMINAL SERVER SOFTWARE OPENLM AGENT
Microsoft Terminal ServerHome Tested, Fully Supported
All versions Citrix terminal serverHome Tested, Fully Supported
OPENLM for ESRI ArcGIS (Arcview, ArcEditor, ArcInfo)
OpenLM for ESRI ArcGIS provides dedicated functionality for ESRI’s ArcGIS Software. The OpenLM Agent supports ESRI ArcGIS Versions 9.3, 10, 10.1, 10.2.2, 10.3, 10.3.1, 10.4.1, 10.5, 10.6, 10.6.1, 10.7 as well as ArcGIS Pro 2.0 – 2.3.3 . For versions older than 10.4 of ArcGIS, it is necessary to install .NET Framework 3.5.





OPENLM for Autodesk
OpenLM provides dedicated functionality for Autodesk software. OpenLM supports Autodesk Versions 2007 through 2019.
OpenLM for Autodesk software supports any platform based on Autodesk Autocad. It is designed to provide full functionality with any other Autodesk software, e.g. Autodesk Inventor, Autodesk Architect, Autodesk Civil 3D, etc.

OpenLM Directory Synchronization Service & Synchronization Agent System Requirements



Hardware:

  • Dual core CPU
  • 4 GB memory (Recommended – 8 GB)



Platform: Windows.

Dependencies: .NET Framework 4.5.2 or higher is required to run the installer.

DSS & DSA are self-contained .NET Core applications – no runtimes are required to run the actual software as all files and libraries come bundled with the default installers.

Port configuration:
Port 8081 must be free when installing DSA. If it is occupied and you get an error during the installation stage, edit the kestrel.config file in the DSA installation folder (C:\Program Files\OpenLM\OpenLM Directory Synchronization Agent), change the port number and restart the Directory Synchronization Agent service.

Additionally, if installing DSS and DSA on separate machines from OpenLM Server, you will have to make sure that proper firewall rules are set for the application ports:

OpenLM Server machine: inbound for 5015, outbound for 7026
DSS machine: both inbound and outbound for 7026
DSA machine: outbound for 7026

Supported directory services:

OpenLM DSS synchronizes with the following LDAP directory services:

  • Microsoft Active Directory
  • NetIQ eDirectory
  • ApacheDS
  • AzureAD



Supported databases:

DSS can be configured to use external databases. The following database types are supported:

  • MS SQL Server:
    Versions 2012, 2014, 2016, 2017, 2019 are tested and supported.
  • MySQL Server:
  • MySQL v5.7 and 8 are supported.
  • MariaDB Server v10.5 (as a current stable version we have tested).



Note you must create a new empty database.

Note that collation must be enabled. Both case-sensitive and case-insensitive databases are accepted.

To create an empty MS SQL database, use these scripts for a case sensitive/insensitive database respectively:

CREATE DATABASE DSS_Linux49 COLLATE Latin1_General_CI_AS
CREATE DATABASE DSS_Linux49 COLLATE Latin1_General_CS_AS



To create an empty MySQL 8 database, use these scripts for a case sensitive/insensitive database respectively:

CREATE DATABASE `DSS_Linux49 ` /*!40100 DEFAULT CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_as_ci */;
CREATE DATABASE `DSS_Linux49 ` /*!40100 DEFAULT CHARACTER SET utf8mb4 COLLATE utf8mb4_0900_as_cs */;

OpenLM DSS UI
OpenLM DSS UI is the management interface. It is applicable to any standard browser. We tested it on the following browser types:

Mozilla Firefox
It is recommended to use the latest version.

Microsoft Edge
It is recommended to use the latest version.

Google Chrome
It is recommended to use the latest version.

Other considerations:

  • If you previously used the integrated LDAP solution that came with OpenLM Server v4.x and you did not experience performance issues or processing hang-ups, you can install DSS & DSA on the same machine as OpenLM Server.
  • For systems that anticipate a high load and a huge amount of synchronization data (tens of thousands of users), it is possible to install DSS on a separate machine to offset the load off the OpenLM Server machine.
  • For systems where DSS & DSA will be deployed separately, it is recommended that DSA be placed on the same subnet as the directory service, as close as possible to the machine hosting it to reduce network latency.



OpenLM Reports Scheduler System Requirements



Hardware:

  • Dual core CPU
  • 4 GB memory (Recommended – 8 GB)



Platform: Windows. Linux is not supported.
